Metal Push Button Switch M12F-F11MP Φ12
Hegxing supplies various of metal push button switch, include metal, illumination, touch, connector and high current series, which is wildly apply to machine, equipment, vehicle, etc.
The metal push button switches have advantages of economy, durability, easy mounting.
Specification
| Mounting diameter | Φ 12 mm |
| Head type | Flat round type |
| Switch combination | 1NO |
| Operating type | Momentary type |
| Connection type | Pin type |
| Suitable panel thickness | 1 ~ 15 mm |
| Switch type | Slow moving double contact |
| Switch rating | Ui: AC 250 V / Ith: 5 A |
| Contact resistance | ≤ 50 mΩ |
| Insulation resistance | ≥ 1000 mΩ |
| Insulation strength | 2000 VAC |
| Temperature range | -20 ~ 55 ℃ |
| Mechancial life | ≥ 1,000,000 cycles |
| Electrical life | ≥ 200,000 cycles |
| Screw torque | 5 ~ 14 N.m |
| Operating pressure | ≤ 4 N |
| Operating limits | 2 mm |
| Case & Button Material | Stainless steel / Nickel plated barss / Aluminum alloy oxide |
| Base Material | Plastics |
| Contact Material | Silver alloy |
| Protection grade | IP65, IK08 |
Model Explanation
| M | 7 | A | -F | 10 | M | P | -S | R | -S | |
| ① | ② | ③ | ④ | ⑤ | ⑥ | ⑦ | ⑧ | ⑨ | ⑩ | |
| ① | Series M: Metal series I: Illumination series T: Touch series L: Large current series C: Connector series |
|||||||||
| ② | Mounting diameter Φ7 / Φ8 / Φ10 / Φ12 / Φ16 / Φ19 / Φ22 / Φ25 / Φ30 |
|||||||||
| ③ | Style Code | |||||||||
| ④ | Head type F: Flat round type H: High flat round type B: Ball type R: Rotation type K: Key type |
|||||||||
| ⑤ | Switch combination 10: 1NO 01: 1NC 11: 1NO + 1NC 22: 2NO + 2NC |
|||||||||
| ⑥ | Operation type M: Momentary type L: Latching type |
|||||||||
| ⑦ | Connection type P: Pin type T: Terminal type |
|||||||||
| ⑧ | Illumination type S: Single point A: Annular M: Multipoint SA: Single point + Annular |
|||||||||
| ⑨ | Illumination color R: Red / G: Green / Y: Yellow / O: Orange / B: Blue / W: White |
|||||||||
| ⑩ | Case material S: Stainless steel B: Nickel plated brass A: Aluminum alloy oxide P: Plastics |
|||||||||
